Stainless Steel Rexnord Flexible Disc Coupling 30000 Nm For Petroleum Machinery
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xMaterial | Stainless Steel | Feature | High Speed |
---|---|---|---|
Application | Hash Working Environment | Advantage | Normal Operation |
Nominal Torque | 240-110000N.m | Selection | Technicians Help You Choose |
Warranty | 2 Years | Product Name | Flexible Disc Coupling |
Main Stucture | Disc | ||
High Light | 30000 Nm Flexible Disc Coupling,Stainless Steel Flexible Disc Coupling,rexnord gear coupling |
High speed Normal operation Flexible Disc Coupling for petroleum machinery
Transmission system of Flexible Disc Coupling shafting: Shafting transmission usually connects the main and driven shafts by one or several diaphragm couplings to form a shafting transmission system to transmit rotation or motion. Flexible Disc Coupling is mainly due to the shaft connection of the motor, reducer and working machine. Its shaft hole form, connection form and size mainly depend on the type and size of the connected shaft. The product design is generally based on cylindrical and conical shaft depths. Standard design shaft, shaft depth standard is for shaft design. In the structural design and series design of various forms of metal Flexible Disc Coupling, the shaft hole range (maximum) of the metal diaphragm coupling is determined based on the size of the transmission torque, the structure of the Flexible Disc Coupling and the strength of the hub. and the minimum shaft hole) and the length of the shaft hole, each specification has only one shaft hole length.
Technical Specifications:
Size | Nominal Torque TKN (Nm) |
Peak max. |
Max. Speed | Weight (kg) |
Massen- Moment of Intertia (kgm2) |
Permissible Axial Misalignment ±Δkazul (mm) |
Permissible Angular Misalignment ±Δkwzul °(Degrees) |
d1/d2 (mm) |
L (mm) |
Z (mm) |
P (mm) |
L1/L2 (mm) |
Standard (mm) |
A (mm) |
B (mm) |
|
Without balancing (1/min) |
With balancing (1/min) |
|||||||||||||||
278-8 | 20000 | 40000 | 2800 | 7000 | 59 | 0.573 | 3.7 | 0.5° | 124 | 469 | 177 | 21.2 | 125 | 219 | 278 | 174 |
302-8 | 30000 | 60000 | 2560 | 6400 | 77 | 0.878 | 4.0 | 0.5° | 135 | 505 | 186 | 24.4 | 135 | 235 | 302 | 190 |
325-8 | 37000 | 74000 | 2400 | 6000 | 92 | 1.199 | 4.3 | 0.5° | 145 | 544 | 202 | 26.0 | 145 | 254 | 325 | 205 |
345-8 | 46000 | 92000 | 2200 | 5500 | 112 | 1.660 | 4.6 | 0.5° | 155 | 580 | 214 | 28.2 | 155 | 270 | 345 | 217 |
380-8 | 63000 | 126000 | 2040 | 5100 | 150 | 2.715 | 5.0 | 0.5° | 170 | 637 | 233 | 32.0 | 170 | 297 | 380 | 238 |
410-8 | 86000 | 172000 | 1880 | 4700 | 195 | 4.110 | 5.4 | 0.5° | 180 | 690 | 254 | 33.2 | 185 | 321 | 410 | 255 |
440-8 | 110000 | 220000 | 1740 | 4350 | 230 | 5.540 | 5.8 | 0.5° | 195 | 725 | 262 | 36.4 | 195 | 335 | 440 | |
Our Strategic Partners
Founded in 2003, Shanghai Reijay Hydraulic & Transmission Tech Co., Ltd focus on mechanical power transmission coupling, hydraulic system spare parts and heat exchanger products (oil heating and cooling equipment) manufacture and export. We also provide relevant technical support and service. We also serve customers with the design, assembly, remoulding and maintenance of industrial automation components (pneumatic, hydraulic, PLC), industrial intelligent systems, hydraulic power units and drive sections.
Q: Who are we?
We are based in Shanghai, China, started in 2003, sell to Domestic Market(50.00%), North America(25.00%), Europe(5.00%), Africa(5.00%), Southeast Asia(5.00%), South America(5.00%)... There are about 180-300 people in our office and factory.
Q: How can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment
Q: What information should I tell you to confirm the product?
Motor drawing or other technique parameters
Q: What can you buy from us?
Couplings, Bellhousings, Oil tanks, Cleaning Covers, Coolers, Hydraulic parts, etc.
Q: Why should you buy from us, not from other suppliers?
We are a professional OEM manufacturer with 20 years of history, focusing on mechanical power transmission coupling, hydraulic system spare parts and heat exchanger product manufacture and export. We also provide relevant technical support and service.
Q: What is your product warranty period?
We offer 2-10 years of service life since the vessel departure date left China.
Q: What services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF, EXW, CIP, FCA, Express Delivery;
Accepted Payment Currency: USD, EUR, HKD, CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,PayPal,Western Union;
Language Spoken: English, Chinese, Spanish
