15 Gallon Aluminium Hydraulic Oil Tank OEM ODM
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Features | Convenient For Liquid Level Monitoring | Material | Aluminum Alloy |
|---|---|---|---|
| Working Temperature | +110℃ | Applicable Medium | Various Hydraulic Oils |
| Advantage | Good Heat Dissipation | Manufacturing Method | 2000-4000 Ton Press High-pressure Casting Aluminum Forming |
| Warranty | 2 Years | Specification | Capacity Various Specifications |
| Name | Hydraulic Oil Tank | Custom | Yes |
| High Light | Aluminium Hydraulic Oil Tank,ODM Hydraulic Oil Tank,OEM 15 gallon hydraulic tank |
||
Product Description
Convenient for liquid level monitoring Low oil drain valve setting Good heat dissipation Hydraulic Oil Tank
In order to keep the oil clean, the Hydraulic Oil Tank has a peripherally sealed cover plate, and an air filter is installed on the cover plate. Oil filling and ventilation are generally completed by an air filter.
In order to facilitate oil draining and cleaning, the bottom of the Hydraulic Oil Tank should have a certain slope, and an oil drain valve should be set at the lowest point. For fuel tanks that are not easy to open, a cleaning hole should be provided to facilitate the cleaning of the interior of the fuel tank.
The bottom of the Hydraulic Oil Tank set a distance from the ground to facilitate handling, oil discharge and heat dissipation. A liquid level gauge is also set up to monitor the liquid level.
Technical Specifications of Hydraulic Tank:
| SB | |||||
| Bores for oil level gauge | |||||
| without | |||||
| withSB | |||||
| SF1 | |||||
| Bores for oillevelgauge | |||||
| without | |||||
| SF1 | Oil level gauge 76 mm | ||||
| SF2 | Oillevel gauge 127 mm | ||||
| SF3 | Oil level gauge254mm | ||||
| KL13 | Oil eye G1/4" | ||||
| Al 8 | Oil eye G3/4" | ||||
| KL33 | Oil eye G1" | ||||
| SD | |||||
| Material reservoir lid | |||||
| Steel | SD | ||||
| NG30 | |||||
| Nominal size | 3.5 | ||||
| 6.5 | |||||
| 8 | |||||
| 12 | |||||
| 13 | |||||
| 20 | |||||
| 30 | |||||
| 44 | |||||
| 70 | |||||
| 130 | |||||
| 200 | |||||
| Bores for bellhousing | |||||
| without | |||||
| 140 | NG6.5 | ||||
| NG 12/13 | |||||
| 160 | NG6.5 | ||||
| NG 12/13 | |||||
| NG20 | |||||
| 200 | NG12/13 | ||||
| NG20 | |||||
| NG30 | |||||
| NG44 | |||||
| 250 | NG20 | ||||
| NG30 | |||||
| NG44 | |||||
| NG70 | |||||
| 300 | NG30 | ||||
| NG44 | |||||
| NG70 | |||||
| Size of reservoir | Effective volume | Specific cooling capacity | Cooling capacity* | Surface with reservoir lid | Weight |
| V[l] | VN[I] | P/Δt [W/K] | P[kW]Δt = 40K | [m2] | [kg] |
| NG3.5 | 3 | 4 | 0.16 | 0.15 | 1.4 |
| NG6.5 | 6 | 9 | 0.36 | 0.25 | 1.7 |
| NG8 | 6.5 | 11 | 0.44 | 0.3 | 2.5 |
| NG12 | 10 | 15 | 0.6 | 0.35 | 2.3 |
| NG13 | 11 | 15 | 0.6 | 0.4 | 2.8 |
| NG20 | 17 | 18 | 0.72 | 0.5 | 4.3 |
| NG30 | 27 | 23 | 0.92 | 0.75 | 5 |
| NG44 | 40 | 26 | 1.04 | 1 | 7 |
| NG70 | 63 | 29 | 1.16 | 1.3 | 10 |
| NG130 | 123 | 52 | 2.10 | 1.93 | 25 |
