90L Nylon Sleeve Gear Coupling Lubricated Motor Pump Coupling

  • 90L Nylon Sleeve Gear Coupling Lubricated Motor Pump Coupling
  • 90L Nylon Sleeve Gear Coupling Lubricated Motor Pump Coupling
  • 90L Nylon Sleeve Gear Coupling Lubricated Motor Pump Coupling
Place of Origin China
Brand Name REIJAY
Certification Provided
Model Number B24
Minimum Order Quantity 1 set
Price Negotiable
Packaging Details Available upon request
Delivery Time Negotiable
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 500 sets/ month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Nylon Sleeve Gear Coupling Working Environment Fans Water Pumps Lubricated Pumps
Warranty 2 Years Material Nylon
Advantage High Mechanical Strength Application Flexible Transmission Between Shafts
Customize Available Upon Request
High Light

90L Nylon Sleeve Gear Coupling

,

REIJAY Nylon Sleeve Gear Coupling

,

Lubricated Motor Pump Coupling
Leave a Message
Product Description

High mechanical strength Good toughness Impact resistance Nylon Sleeve Gear Coupling



      Nylon Sleeve Gear Coupling wear-reducing, wear-resistant, self-lubricating properties, can work effectively in the condition of less or no oil, generally 2-8 times more wear-resistant than copper and babbitt.



      High mechanical strength, good toughness, impact resistance, fatigue resistance, shock absorption and noise reduction. It has good burying performance for foreign objects and good compliance performance. It can work under harsh conditions where abrasive particles and impurities exist to prevent seizure and damage to the shaft.







Technical Specification



Motor
Size

WilteSfMift
Dxl [mm]

 n=750 [1/min] Power P Coupling Tk max. [Nm] n = 1000 [1/min] Power P Coupling Tk max. [Nm] n = 1500 [1/min] Power P Coupling Tk max. [Nm]

n=3000

(1/min] PawwP

 Coupling Tk max. [Nm]
1500 [1/mln] 3000 [1/mm] [kW] TAN [Nm] [kW] TAN [Nm] [kW] TAN [Nm] [kW] TAN [Nm]
56 9x20 　 　 14 20 0.037 0.43 14 20 0.06 0.4 14 20 0.09 0.3 14 20
0.045 0.52 0.09 0.6 0.12 0.4
63 11x23 　 　 14 20 0.06 0.7 14 20 0.12 0.9 14 20 0.18 0.6 14 20
0.09 1.1 0.18 1.2 0.25 0.9
71 14x30 0.09 1.4 14 20 0.18 2 14 20 0.25 1 14 20 0.37 1.3 14 20
0.12 1.8 0.25 2.8 0.37 2.5 0.55 1.9
80 19x40 0.18 2.5 19 32 0.37 3.7 19 32 0.55 3.7 19 32 0.75 2.5 19 32
0.25 3.5 0.55 5.5 0.75 5 1.1 3.7
90S 24x50 0.37 5.3 24 40 0.75 7.9 24 40 1.1 7.5 24 40 1.5 4.9 24 40
90L 0.55 7.9 1.1 11 1.5 10 2.2 7.4
100 L 28x60 0.75 11 28 90 1.5 15 28 90 2.2 15 28 90 3 9.8 28 90
1.1 16 3 20 4 13
112M 28x60 1.50 21 28 90 2.2 22 28 90 4 27 28 90 4 13 28 90
132 S 38x80 2.20 29 38 160 3 30 38 160 5.5 36 38 160 5.5 18 38 160
7.5 25
132 M 3 40 4 39 7.5 49 　 　
5.5 55
160M 42x110 4 54 42 200 7.5 74 42 200 11 72 42 200 11 35 42 200
5.50 74 15 49
160 L 7.50 100 11 108 15 98 18.5 60
180M 48x110 　 　 48 280 　 　 48 280 18.5 121 48 280 22 72 48 280
180 L 11 147 15 147 22 144 　 　
200L 55x110 15 196 55 500 18.5 185 55 500 30 195 55 500 30 97 55 500
22 215 37 117
225 S 60x140 55x110 18.50 245 65 780 　 　 65 780 37 245 65 780 　 　 55 500
225 M 22 294 30 292 45 294 45 146
250 M 65x140 60x140 30 390 65 780 37 361 65 780 55 357 65 780 55 176 65 780
280S 75x140 65x140 37 490 80 1400 45 440 80 1400 75 487 80 1400 75 245 65 780
280 M 45 585 55 536 90 584 90 294
315 S 80x170 65x140 55 715 80 1400 75 730 80 1400 110 714 80 1400 110 350 65 780
315M 75 970 100 2400 90 876 100 2400 132 857 100 2400 132 420
315 L 90 1170 110 1070 160 1030 160 513 80 1400
110 1420 132 1200 200 1290 200 641



90L Nylon Sleeve Gear Coupling Lubricated Motor Pump Coupling 0
